PAS 68 Terra Quantum Bollard 7.5t @ 30mph

Frontier Pitts PAS 68 Terra Quantum Bollard 3D illustrated here as a single Quantum Bollard amongst Static Terra Bollards

PAS 68 – 7.5t @ 30mph – Rising

The World’s first BSi PAS 68 side folding bollard; the ULTIMATE BREAKTHROUGH INNOVATION for Hostile Vehicle Mitigation.

The UNIQUE Terra Quantum Bollard is a Shallow Depth, Side Folding Retractable HVM Terra Bollard which has been successfully PAS 68 impact tested stopping a 7.5t vehicle travelling at 30mph (48kph), which equates to 667kJ, with ZERO PENETRATION.

The Quantum Bollard Innovative Direction of Travel – Side Folding Bollard uniquely raises and lowers – with a small footprint and encroachment of foundation.

The Retractable Bollard is automatic and twinned with a static unit.

The Bollard has a padlockable locking pin within the bollard enclosure. 2no. Terra Quantum Bollards back to back form a 4m clear aperture. Designed for ease of installation and maintenance.

Lifted Height: 925mm
IWA 14 Tested dimensions: lift height 925mm

Non-powered Terra Quantum Bollard available – please click here

Contact Technical Sales

BIM & NBS Specifications

PAS 68 Rising Terra Quantum Bollard 7.5t@30mph Specifications

Features

PAS 68 Rising Terra Quantum Bollard 7.5t@30mph

Basic Specs

PAS 68 Classification Code: V Rising Bollard /7500[N2]/48/90:0.0/1.5

Lift height: 925mm

More details

Construction: S355 structural steel plate is a high-strength low-alloy European standard structural steel

Automatic Terra Bollard Finish: Polyester Powder Coated Painted finish as standard or stainless steel clad.

Option of Anti Slip Paint for the top plate.

Terra Bollard Operation: Each bollard has a manual hydraulic power unit including hydraulic reservoir, manual hand pump and manual release valve within the bollard enclosure.

Automatic Terra Bollard Safety: LED Traffic light heads, hold to run controls

Duty Cycle: 100% duty rating

Terra Bollard Durability: Fully functional after PAS 68 impact test

Controls: The programmable logic controller (PLC) with built in safety features. Hold to run push buttons or VHF system. Can be controlled remotely as long as CCTV systems are in place. Push button as supplied as standard

Accreditations: Secured by Design, BRE Global

Civil Engineering

For more information please contact the Technical Sales Department on

01293 422800 or email:

[email protected]

Electrical Engineering

Industry standard electricals

Electrical Requirements: Single or three phase, Depending on configuration

Specifications subject to change and are dependant on product options. Please contact Frontier Pitts to request more information.

Product Video

Photo Gallery

Accessories

Stainless Steel Bollard Clad	Bollard tube Stainless Steel Clad
Finish: Satin Polished Stainless Steel	Satin–polished 320 grit (0.5 micron) stainless steel finish
Finish: Bead Blasted Stainless Steel	Our bead blasting stainless steel finish achieves no pitting or distortion of the final surface. N.B. distortion is dependant on material thickness
Finish: Powder Coating	Powder coated paint finish in clients choice of RAL colour.
Reflective Banding	Another option for the finish of the bollard is reflective banding. The reflective banding can be deemed a necessity to ensure the bollard stands out from the architecture of the landscape and/or building. Bollard banding is available in a range of colours and dimensions, with option on the number of bands on the bollard, and position (top of bollard, top and bottom of bollard). The colour of the banding can also reflect the branding of the site company.
Personalised Engraving	In addition to reflective banding on the static bollards to incorporate the sites corporate brand image, Frontier Pitts can also provide corporate engraving on the stainless steel bollard sleeve.
Signage	Warning and information signs installed on the barrier boom such as ‘STOP’ ‘NO EXIT’ and ‘NO ENTRY’
Traffic Light System	Standard Traffic Light systems are highly recommended to be installed with all road blocker and bollard systems to advise all users of its position, and are supplied as standard. 100mm LED traffic light head can be pole or mounted on control cabinet
Traffic Light Cage	Vandal resistant traffic light cages
Totem Traffic Light System	Totem Traffic Light systems are optional and an upgrade to the standard Traffic Light system. Traffic Lights are highly recommended to be installed with all road blocker and bollard systems to advise all users of its position.
