Hinged/Swing Gates

Automatic Hinged/Swing Security Gates

Security Hinged Gates, or Security Swing Gates as they are also known, are designed to provide a high degree of security within a fenceline where the runback required for a sliding gate installation is not available.

Hinged and Swing gates are available in automatic and manual models, in a wide range of styles to compliment both contemporary and traditional architectural designs. They can also be custom-designed to match a company’s specific requirements.

Automatic Hinged/Swing Security Gates are powered by actuators.
For our full range of actuators, please see our Actuator Product page.

Automatic Hinged/Swing Security Gates Single Leaf Maximum width: 5000mm
Automatic Hinged/Swing Security Gates Double Leaf Maximum width: 10000mm
Standard height: 2400mm
Maximum height: 5000mm
Bespoke available

Contact Technical Sales

Automatic Hinged/Swing Security Gates Specifications

Features

Automatic Hinged/Swing Security Gates

Basic Specs

Hinged/Swing Gate

Automatic Hinged Single Leaf Maximum width: 5000mm

Double leaf Leaf Maximum width: 10000mm

Standard height: 2400mm

Maximum height: 5000mm

Bespoke available

Manual and Automatic Hinged/Swing Gates available.For Automatic Hinged/Swing Gates, please see Actuator page for more information.

Bespoke available

More details

The gate leaf is a fully welded construction of rectangular hollow section, low carbon steel to BS4848 Pt.2. Combination of vertical 50mm x 25mm ERW bar infill at approximately 180mm centres backed by 50mm square galvanised weld mesh, painted to match Standard colour range: Any colour in the RAL colour range

Finish: Various options available, including: Shotblasted, hot zinc sprayed, primed & finished with a final coat of polyurethane paint. Alternatively, acid dipped then hot galvanized available on smaller gates.

Various security infills available including bar, security weldmesh, sheet, and bespoke such as wood and ornate.

100 % Operating duty cycle – designed for continuous & frequent use.

Typical operating speeds dependent on automation type and configuration.

Hinged Gates Safety control systems: Vehicle detector loops, safety photocells, ultra-sonic sensors and safety edges are available. Accessories: Signage, audible alarms and flashing beacons.

Hinged Gates Access controls: A wide range of access control systems are available.This is subject to a risk assessment to ensure the automatic equipment complies to BS EN 12453

Civil Engineering

Dependent on Automation, please see Actuator page.

Gate Post Foundation: L:1600mm W:1300mm x D:1000mm
Dependent on Automation, please see Actuator page.(Note: Power and control wiring ducts to be incorporated into foundations)
For more information please contact the Technical Sales Department on

01293 422800 or email:

[email protected]

Electrical Engineering

Industry standard electricals

Electrical Requirements: Dependent on actuator and configuration

Specifications subject to change and are dependant on product options. Please contact Frontier Pitts to request more information.

Photo Gallery

Accessories

Signage	Warning and information signs are recommended to be installed with all automatic equipment to advise users of its operation
Hinged Gate Warning Sign	Indicates and warns users of the swing of a hinged gate during opening and closing
Traffic Light System	Traffic Light systems can be installed with Automatic Gate systems to advise all users of its position. 100mm traffic light head can be pole or mounted on control cabinet
Vehicle Detector Loops	Vehicle detector loops installed beneath the road surface to detect vehicles. This will prevent the automatic equipment from closing on a vehicle within the aperture. Safety induction loops cut into the road surface. This will prevent the gate from closing on a vehicle within the aperture.
Safety Photocells	Safety Photocells produce beams of light which cross the road way to monitor vehicle and pedestrian movement. If an object breaks this beam, the automatic equipment will stop & reverse. On gate installations, two pairs of photocells are usually fitted. Ultra Sonic Sensors are also available.
Gate Safety Edge	Safety Edges are normally fitted to automatic gates. However they can also be installed beneath a barrier boom. Safety edges prevent the barrier lowering on a person or vehicle in the event it is activated. Safety edges are flexible strips which, if depressed, send a signal to the power source to stop.
Automatic Hinged Gates	For Automatic Gates, safety accessories and devices, please view the Actuator product page.
Gate Infill	Weldmesh should be clipped to the gates infill bars infill to prevent pedestrians putting their limbs through. Other infills include palisade pales, sheet and wood infills. For more information please Security Gate Infills page
Sounder	Sounders/Audible Alarms provide an audible warning that the automatic equipment is in operation.
Flashing Beacon	Flashing Beacons provide a visual warning that the automatic equipment is in operation.
