Bollards
Frontier Pitts manufacture a range of Automatic Rising Bollards and Static Bollards, including the Anti-Ram Rising iBollard. Our Hostile Vehicle Mitigation (HVM) Bollards including Rising/Retractable Bollards, Static, Shallow Static and Removable Terra Bollards which have all been successfully vehicle impact tested to IWA14 and PAS68 stopping 7.2t/7.5t vehicle travelling at a range of speeds and energies.
Automatic Rising Bollards and Static Bollards
Click on the bars below to toggle open / close the category
Anti-Ram Security Bollards (non impact tested)
The Automatic Rising Bollard is a retractable anti-ram bollard, hydraulically driven with a lift height of 600mm.
IWA14 & PAS68 Impact Tested Anti-Terrorist Bollards
Rising Terra Bollards
The HVM Automatic Rising Bollard (retractable) vehicle impact tested to IWA 14 with 7.2t @ 80kph (50mph) (PAS68)
Lift Height 1000mm. Interchangeable sleeves to match the static range of bollards
The HVM Automatic Rising Bollard (retractable) vehicle impact tested to IWA 14 with 7.2t @ 48kph (30mph) (PAS68)
Lift Height 1000mm.
The HVM Automatic Side Folding Rising Bollard (retractable) vehicle impact tested to PAS 68 – 7.5t @ 30mph (48kph)
Lift Height 925mm.
The HVM Non-powered Side Folding Rising Bollard (retractable) impact vehicle impact tested to PAS 68 – 7.5t @ 30mph (48kph)
Lift Height 925mm.
The HVM retractable bollard vehicle impact tested to PAS 68 with 7.5t @ 50mph (80kph)
Fully Functional After Impact
Lift Height 900mm. Bespoke available.
Shallow Static Terra Bollards
The IWA 14 Shallow Static Terra Jupiter Bollard is a counter terrorist bollard, successfully IWA 14 vehicle impact tested stopping a 7.2t vehicle travelling at 50mph (80kph)
The PAS 68 Shallow Static Terra Venus Bollard is a counter terrorist bollard, successfully PAS 68 vehicle impact tested stopping a 7.5t vehicle travelling at 30mph (48kph) which equates to 667kJ.
The PAS 68 Single Standalone Shallow Static Terra Neptune Bollard is a counter terrorist bollard, successfully PAS 68 vehicle impact tested stopping a 7.5t vehicle travelling at 40mph (64kph) which equates to 1185kJ.
The Ultra Shallow HVM IWA14 Terra Lunar Bridge Bollard successfully vehicle impact tested stopping 7.2t at 30mph at a shallow angle of 30degrees. Foundation depth of only 75mm!
The Ultra Shallow HVM IWA14 Terra Lunar 180 Bollards & Beam for Bridge Expansion Joint, successfully vehicle impact tested stopping 7.2t at 30mph at a shallow angle of 30degrees
Static Terra Bollards
The PAS 68 Static Terra Jupiter Bollard is a counter terrorist crash bollard, successfully PAS 68 vehicle impact tested stopping a 7.5t vehicle travelling at 50mph (80kph) which equates to 1852kJ.
The PAS 68 Static Terra Neptune Bollard is a counter terrorist bollard, successfully PAS 68 vehicle impact tested stopping a 7.5t vehicle travelling at 40mph (64kph) which equates to 1185kJ.
The PAS 68 Static Terra Mars Bollard is a counter terrorist bollard, successfully PAS 68 vehicle impact tested stopping a 7.5t vehicle travelling at 40mph (65kph) which equates to 1185kJ.
The PAS 68 Static Terra Venus Bollard is a counter terrorist bollard, successfully PAS 68 vehicle impact tested stopping a 7.5t vehicle travelling at 30mph (48kph) which equates to 667kJ.
The IWA 14 Static Terra Comet Bollard is a counter terrorist bollard, successfully IWA 14 vehicle impact tested stopping a 3.5t vehicle travelling at 30mph (48kph).
