LPS 1175 Terra Diamond Turnstile

Frontier Pitts Terra Diamond Turnstile 3D model

Frontier Pitts Ltd has become the first company, and currently only company, to achieve LPS 1175 Issue 6 Security Rating 3 & 4 for their full height Terra Diamond Turnstile.

The Terra Diamond Turnstiles successfully resisted an intensive attack test programme in accordance with LPS 1175: Issue 6.1. Under the category of Building Fabric, this involved a series of attack tests each lasting at least 10 minutes using a wide array of hand tools and battery powered tools.

  • Heavy duty, high security turnstile
  • Anti Return solenoid lock
  • Approved for Government Use, please contact CPNI
  • Power locking bolt – provides turnstile lock down
  • Turnstile seeks next lock position so users cannot become trapped within the unit.
  • Designed and proven to withstand a considerable degree of physical attack
  • Extra high security with a full CPNI approved fence line integration and fixing
  • Robust steel 90 degree rotor
  • Infilled rotor arms prevent climbing and items being passed through the turnstile
  • Allows only single file authorised access
  • Metal reinforced high security lid
  • Painted to clients choice of RAL colour
  • AC Interface and microprocessor control board
  • Status indicator with red & green light
  • Heavy duty, vandal resistant head mechanism
  • Fail secure – turnstile will remain secure during power failure.
  • BS EN 1627:2011 Requirements and classification for Pedestrian doorsets, windows, curtain walling, grilles and shutters. Burglar resistance.
  • Installed in many Nuclear & Utility sites Nationally and Internationally
  • Red Book Listing
  • LPS 1175 Terra Diamond Turnstile Specifications SR3 & 4

    Features

    The LPS 1175 Terra Diamond Turnstile

      Basic Specs

    • LPS 1175 Terra Diamond Turnstile Specifications SR3 & 4
    • Height: 2387mm
    • More details

    • Construction: High-strength sheet steel blades. (Grade 4 has additional reinforcing for increased resistance to attack)
    • Finish: Various options available, including: Shotblasted, hot zinc sprayed, primed & finished with a final
      coat of polyurethane paint. Client to advise RAL paint number. This process provides a 20-year corrosion protection system for exterior, industrial polluted inland sites to BS5493, 1977 (Revised 1984). Alternatively, acid dipped then hot galvanized. Any colour in the RAL colour range.
    • Options: Red/Green Indicator Lights, Manual release handle, LED walkway lighting
    • Duty cycle: 100% duty rating
    • BS EN 1627:2011 Requirements and classification for Pedestrian doorsets, windows, curtain walling, grilles and shutters. Burglar resistance.
    • Controls: The programmable logic controller (PLC) with built in safety features will accept inputs from access control systems including access card, voice, etc. Push button as supplied as standard

    Civil Engineering

    For more information please contact the Technical Sales Department on

    01293 422800 or email:

    sales@frontierpitts.com

    Electrical Engineering

    Industry standard electricals

    Electrical Requirements: 230v 50Hz 2 amp supply single phase, depending on configuration

    Specifications subject to change and are dependant on product options. Please contact Frontier Pitts to request more information.



    Photo Gallery

    Accessories

    Barrier Signage

    Warning and information signs installed on the barrier boom such as ‘STOP’ ‘NO EXIT’ and ‘NO ENTRY’

    HGV Signage

    Warning and information signs installed on the barrier boom at a height more visible to HGV users.

    Pedestrian Warning Sign

    Normally placed on the barrier cabinet. Warns pedestrian of the automatic barrier.

    Traffic Light System

    Traffic Light systems are highly recommended to be installed with all road blocker and bollard systems to advise all users of its position. 100mm traffic light head can be pole or mounted on control cabinet

    Vehicle Detector Loops

    Vehicle detector loops installed beneath the road surface to detect vehicles. This will prevent the automatic equipment from closing on a vehicle within the aperture. Safety induction loops cut into the road surface. This will prevent the gate from closing on a vehicle within the aperture.

    Safety Photocells

    Safety Photocells produce beams of light which cross the road way to monitor vehicle and pedestrian movement. If an object breaks this beam, the automatic equipment will stop & reverse. On gate installations, two pairs of photocells are usually fitted. Ultra Sonic Sensors are also available.

    Barrier Safety Edge

    Safety Edges are normally fitted to automatic gates. However they can also be installed beneath a barrier boom. Safety edges prevent the barrier lowering on a person or vehicle in the event it is activated. Safety edges are flexible strips which, if depressed, send a signal to the power source to stop.
