NPSA Terra Diamond Turnstile

Approved for UK Government Use, for details contact NPSA

The Terra Diamond Turnstiles successfully resisted an intensive attack test programme. Under the category of Building Fabric, this involved a series of attack tests each lasting at least 5 minutes using a wide array of hand tools and battery powered tools.

Heavy duty, high security turnstile
Anti Return solenoid lock
Approved for Government Use, please contact NPSA
Power locking bolt – provides turnstile lock down
Turnstile seeks next lock position
Designed and proven to withstand a considerable degree of physical attack
Extra high security with a full NPSA approved fence line integration and fixing
Robust steel 90 degree rotor
Infilled rotor arms prevent climbing and items being passed through the turnstile
Metal reinforced high security lid
Painted to clients choice of RAL colour
AC Interface and microprocessor control board
Status indicator with red & green light, buzzer and signage
Heavy duty, vandal resistant head mechanism
Fail secure – turnstile will remain secure during power failure.
BS EN 1627:2011 Requirements and classification for Pedestrian doorsets, windows, curtain walling, grilles and shutters. Burglar resistance.
Installed in many Nuclear & Utility sites Nationally and Internationally

NPSA CSE Catalogue – Frontier Pitts Diamond S Turnstile

Secured by Design

Contact Technical Sales

NPSA Terra Diamond Turnstile Specifications

Features

The NPSA Terra Diamond Turnstile

Basic Specs

Approved for UK Government Use, for details contact NPSA

Height: 2387mm

More details

Construction: High-strength sheet steel blades. (Grade 4 has additional reinforcing for increased resistance to attack)

Finish: Various options available, including: Shotblasted, hot zinc sprayed, primed & finished with a final
coat of polyurethane paint. Client to advise RAL paint number. This process provides a 20-year corrosion protection system for exterior, industrial polluted inland sites to BS5493, 1977 (Revised 1984). Alternatively, acid dipped then hot galvanized. Any colour in the RAL colour range.

Options: Red/Green Indicator Lights, Manual release handle, LED walkway lighting

Duty cycle: 100% duty rating

BS EN 1627:2011 Requirements and classification for Pedestrian doorsets, windows, curtain walling, grilles and shutters. Burglar resistance.

Controls: The programmable logic controller (PLC) with built in safety features will accept inputs from access control systems including access card, voice, etc. Push button as supplied as standard

Civil Engineering

For more information please contact the Technical Sales Department on

01293 422800 or email:

[email protected]

Electrical Engineering

Industry standard electricals

Electrical Requirements: 230v 50Hz 2 amp supply single phase, depending on configuration

Specifications subject to change and are dependant on product options. Please contact Frontier Pitts to request more information.

Photo Gallery

Accessories

Signage	Warning and information signs installed on the barrier boom such as ‘STOP’ ‘NO EXIT’ and ‘NO ENTRY’
Turnstile Lights	Lights available in the lid of the turnstile
Cowled Switch	Exit buttons on pedestrian gates are usually cowled to prevent users reaching the button from the insecure side.
Pedestrian Guard Rail	A Pedestrian Guard Rail (fence panels) should be fitted around the runback area of the sliding gate. This is to prevent serious injury to a person should they stray into that area whilst the gate is operating.
