IWA 14 Terra Universal Bollard 7.2t @ 80kph

IWA 14 – 7.2t @ 50mph

Introducing the latest model of Terra Rising Bollard, which has been successfully impact tested to the new International IWA-14 specification, stopping a 7.2t vehicle travelling at 80kph (50mph).

The fully automatic, easy glide hydraulically driven Rising Bollard mechanism provides outstanding 360° Hostile Vehicle Mitigation protection from the threat of VBIED’s.

The Terra Universal Bollard has been designed to complement the Static Bollard diameters of our HVM Planet range. This unique characteristic allows inter-changeable diameter sleeves to be fitted to the rising bollards inner core, creating a versatile and stylish perimeter protection solution. For Sleeve options please see Accessories tab or the Bollard Sleeve page

This environmentally friendly retractable bollard requires 30% less steel than its predecessor, allowing for ease of installation in a simple fabric mesh pocket. The visibly minimised footprint is finished with an attractive hexagonal top plate, and has the option of LED cateye lighting creating a stylish bollard perfect for modern architectural designs.

IWA14-1 Rising Bollards and Static Bollards are required to be installed at 1200mm between upright bollard faces to meet IWA14-2 guidelines.

Retractable Automatic Rising Terra Bollards have an industrial hydraulic pump drive unit. Designed for ease of installation and maintenance. The Retractable Automatic Terra Bollard can be interfaced to any access control systems. Traffic Light System included as standard on all automatic bollard systems.

The Rising Terra Universal Bollard is designed to complement the Static HVM Bollards.

  • Lifted Height: 1000mm
  • IWA 14 Tested dimensions: lift height 1000mm
  • Interchangeable Sleeves

IWA 14 Rising Terra Universal Bollard [email protected] Specifications

Features

IWA 14 Rising Terra Universal Bollard [email protected]

    Basic Specs

  • IWA 14 Classification Code: V Rising Bollard V/7200[N2A]/80/90:6.3
  • Lift height: 1000mm
  • Interchangeable Sleeves
  • More details

  • S355 structural steel plate is a high-strength low-alloy European standard structural steel
  • Automatic Terra Bollard Finish: Polyester Powder Coated Painted finish as standard with the option of Powder Coated or Stainless Steel Sleeves to match 254-356 diameters of the Static HVM Bollards.
  • Option of Anti Slip Paint for the top plate.
  • Automatic Bollard Options: Accumulator – allows a number of operations in power failure mode, EFO(Extra Fast Operation), Manual Hand pump, High Security Cabinet, Anti-tamper alarms
  • Automatic Terra Bollard Safety: Safety-edges, Vehicle Detector Loops, Safety Photocells, LED Traffic light heads, Flashing beacon, Audible alarm
  • Normal Operating Speed/Time: 6-10 seconds, Depending on configuration
  • EFO Operating Speed/Time: up to 3 seconds, Depending on configuration
  • Duty Cycle: 100% duty rating
  • Controls: The programmable logic controller (PLC) with built in safety features will accept inputs from access control systems including access card, voice, etc. Push button as supplied as standard
  • Accreditations: Secured by Design, BRE Global

Civil Engineering

For more information please contact the Technical Sales Department on

01293 422800 or email:

[email protected]

Electrical Engineering

Industry standard electricals

Electrical Requirements 6amp, three phase, 5wire neutral, earth or 6amp, single phase, Depending on configuration

Specifications subject to change and are dependant on product options. Please contact Frontier Pitts to request more information.

Product Video



Photo Gallery

Accessories

Signage

Warning and information signs installed on the barrier boom such as ‘STOP’ ‘NO EXIT’ and ‘NO ENTRY’

Traffic Light System

Traffic Light systems are highly recommended to be installed with all road blocker and bollard systems to advise all users of its position. 100mm traffic light head can be pole or mounted on control cabinet

Traffic Light Cage

Vandal resistant traffic light cages

Accumulator

In the event of a power failure or sabotage, the accumulator can raise and lower the blocker/bollard for a number of predetermined operations. An accumulator is a self contained charged unit with battery backed control system.

Extra Fast Operation

Increases the products speed of operation to a few seconds. Dependent on configuration. Please contact Technical Sales for more information on 01293 422800

Manual Handpump

In the event of a power failure, a hand pump/release can be provided to enable the manual raising and lowering of the blocker/bollard.

Hand drill to operate manual hand pump

Hand drill to operate manual hand pump on a Rising Terra Bollard.

Vehicle Detector Loops

Vehicle detector loops installed beneath the road surface to detect vehicles. This will prevent the automatic equipment from closing on a vehicle within the aperture. Safety induction loops cut into the road surface. This will prevent the gate from closing on a vehicle within the aperture.

Safety Photocells

Safety Photocells produce beams of light which cross the road way to monitor vehicle and pedestrian movement. If an object breaks this beam, the automatic equipment will stop & reverse. On gate installations, two pairs of photocells are usually fitted. Ultra Sonic Sensors are also available.

High Security Cabinet

Provides high security protection to the control cabinet of Frontier Pitts IWA14 & PAS 68 Anti Terra product range. Special Security cabinets can be fitted and tested to BRE 1175 with 6 point security locking mechanism and fire resistance to DIN 4102. High security mauer key lock, Class A, ECBS/ENV 1300 approved, with similar rating to BS EN 1143-1 1997.

Anti Skid Paint

The Terra Bollard’s Top Plate can be fully coated with an anti skid resistant treatment which has been fully tested under laboratory conditions for at least 12 months

Stainless Steel Bollard Sleeves

Frontier Pitts have a portfolio of sleeves for our Planet range of HVM Terra Bollards. Options below include mitre and dome tops, different types of stainless steel finishes and the choice of colour bands and engraving.

Polyester Powder Coated Bollard Sleeves

Frontier Pitts have a portfolio of sleeves for our Planet range of HVM Terra Bollards. Polyester Powder Coated Sleeves pictured here with recessed banding

Stainless Steel Cabinet

As standard, the road blockers/bollards control cabinet is shotblasted and finish with a final coat of polyurethane paint. However a Stainless Steel finish is also available as an option.
